Nyma Care Exposed Valve Doc M Pack For Shower With Concealed Fixings – Satin Stainless Steel – 230404/SS

Nyma Care Exposed Valve Doc M Pack For Shower With Concealed Fixings – Satin Stainless Steel – 230404/SS

Add this Nyma Care Doc M shower pack to your bathroom or wet room today to maintain your independence at home, the pack is also popular and suitable for public spaces and nursing homes. You will have everything you need in this pack to use your bathroom or wet room safely.

Start of your Doc M shower pack with the Nyma Care TMV3 shower valve and diverter kit. The single sequential control for both temperature and flow, ensures a smooth operation. You can have peace of mind with the auto shut off, if in the event of cold or hot water supply failure. It is also easy to keep clean with the simple to use isolation and filer removal. Constructed from brass, this valve and divert kit will stay hygienic, especially with the integral flushing for infection control. What more, the kit is WRAS, TMV3 approved and part M of building regulations. This kit includes a sleek and modern fixed shower head which is near enough impossible to remove or vandalise.

Specifications

• Maximum hot water supply temperature – 65 degrees Celsius
• Maximum statis pressure – 10 bar
• Minimum dynamic pressure – 02 bar MIN, 5 bar MAX
• Connection inlet – 15mm compression
• Connection outlet – G ½”

Made from a robust plastic is the shower hand set has a ¾” threaded connection and 3 stage flow style adjustment paddle.

This Nyma Care wall mounted shower seat is the ideal solution to offer extra help to those in need when using the shower. We can be sure you will have maximum comfortability whilst maintaining your independence and dignity. Constructed from a non-corrosive aluminium and stainless-steel frame with seat drainage holes, this shower seat is protected from water damage and will last for years to come. Simply adjust the seat height to your preferred position for ultimate support when using the shower. The extended projection allows wheelchair users to side slide from their chair to shower seat with ease. Complete with a padded back rest for optimum support with polyurethane padding for maximum hygiene.

The sliding shower head bracket is Part M compliant of building regulations. It has a large button for easy use for those who have limited dexterity and compatible with 32mm diameter rails.

Keep your shower curtain in place with the L-shaped rail, the tubular stainless-steel construction is strong and can be cut to size. Supplied with concealed wall fixings and ceiling stay, we can be sure this rail will keep your shower curtain in place.

To complete your rail, the weighted shower curtain is made from an easy to clean polyester material. The eyelets will allow you to smoothly open and close your shower curtain when required.

You will have a firm hand grip with the 5 round flange grab rails with concealed fixings that are included in the pack, we can be sure you will feel supported and secure when moving from one position to another or standing up and down. All of which are made robust stainless steel, place the grab rails to your preferred positions and heights around your bathroom.

To add to your grab rails, this Doc M pack also comes with 2 lock and lift support rails, made from stainless steel, the support rails are strong, durable and will last for years to come. Simply lift and secure the rails against the wall when not in use, giving you back much needed space in your bathroom or wet room.

Complete your shower Doc M pack with the handy single robe hook. Brightly coloured, the robe hook is ideal for those who are visually impaired. Made from an aluminium construction, it is part M compliant.

Lastly, this shower pack is Doc M compliant, WRAS and TMV3 approved, this gives you the confidence that you are investing in the highest of qualities and ensures it is built for maximum comfort in mind. Most importantly it conforms with part M and G of building regulations.

Key Features

• Colour – Satin Stainless Steel
• Easy to clean and install
• No electrical earthing required
• Essential for any disabled area
• Complies with Part M of the Building Regulations
• TMV3 & WRAS approved valve and diverter
• Concealed valve and diverter with extended levers
• Extended projection shower seat to allow easier side transfer from wheelchair
• Non-corrosive concealed fixings stainless steel grab rails & hinged support rails
• Simple one box solution

What Is Included

• 1 x Doc M shower seat
• 1 x 1 Exposed TMV3 Doc M shower valve
• 1 x Exposed Doc M shower diverter
• 1 x Antivandal overhead shower head
• 1 x Shower head and hose
• 3 x 600mm Stainless steel grab rails with concealed fixings
• 1 x 450mm Stainless steel grab rail with concealed fixings
• 1 x 900mm Stainless steel grab rail with concealed fixings
• 2 x 800mm Stainless steel hinged support rails
• 1 x 1200mm x 1200mm Stainless steel shower curtain rail
• 2 x Weighted shower curtains
• 1 x Sliding Shower head bracket
• 2 x Single robe hook

Dimensions

• Hand Set – 250x85x75mm
• Shower Valve – 160x132mm
• Shower Seat – 1000x467x650mm
• Shower Head Bracket – 65x180x65mm
• Curtain Rail – 25x1200x1200mm
• Curtain – 2000x1800mm (fully flat)
• Small Grab Rail – 450x79x110mm
• Mid Grab Rails – 600xx79x110mm
• Large Grab Rail – 900x79x110mm
• Support Rail – 800x100x182mm
• Robe Hook – 48x119x35mm
